Nuovo Sarvocomando DS3245 Digital Coreless 51KG/0.11sec@8.4V
Nuovo Sarvocomando DS3245 Digital Coreless 51KG/0.11sec@8.4V adatto per automodelli in scala 1/5 1/8 1/10
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
Caratteristiche:
- Motore coreless ad alte prestazioni con rapporto di trasmissione 342:1
- Fino a 51 kgcm di coppia di stallo a 8,4 V
- Risposta rapida: fino a 0,11 sec/60°
- Doppio cuscinetto a sfere per un funzionamento regolare
- Resistente all'acqua secondo lo standard IP66
- Intervallo di controllo 180° o 270° (PWM)
- Cavo servo standard a 3 fili da 300 mm
Specifiche tecniche:
| voltaggio: | 5,0 V | 6,0 V | 7,4 V | 8,4 V |
| Coppia (stallo): | 35 kg cm | 40 kg cm | 46 kg cm | 51 kg cm |
| Velocità (senza carico): | 0,18 secondi/60° | 0,15 secondi/60° | 0,13 secondi/60° | 0,11 secondi/60° |
| Motore: | Senza nucleo | |||
| Rapporto di trasmissione: | 342 | |||
| Cuscinetti: | Raddoppiare | |||
| Frequenza: | 50330Hz | |||
| Gamma PWM: | 500-2500 µs | |||
| Banda morta: | 2µsec | |||
| Rotazione: | Antiorario | |||
| Angolo: | 180° o 270° | |||
| Misurare: | 40 × 20 × 38,5 mm | |||
| Peso: | 60 g | |||
| Impermeabile: | IP66 | |||
- Etá Consigliata
- 14+
- Per Tracciati
- Off Road
On Road - Alimentazione
- Elettrica
